The COB LED Grow Light Explained and Reviewed

157 Shares

Have you heard about COB LED grow lights, and now you’re wondering what all the fuss is about?

Then look no further, because I've got a treat for you.

In this article, I want to go over the COB LED phenomenon. I will explain what they are, and how they’re a significant development for indoor grow light technology and also why they’re being rapidly deployed into many indoor grow rooms all across the planet.

Has LED technology finally become a viable and affordable alternative to replace the big, bulky, and hot HID grow lights?

Do COB LEDs justify the cost?

Keep reading and let's find out!​

Note: This article is meant to serve as a primer on COB LEDs and an extension of my previous article on full spectrum LED grow lights. If you want to know more about full spectrum LED grow lights, take a look at that article as I go deeper into the specifics of LED technology and how it compares to other alternatives.

Listen to this post on the Epic Gardening Podcast:

Subscribe to the Epic Gardening Podcast on iTunes

What is a COB LED?

A COB (short for Chip-on-Board), is an LED packaging technology that describes mounting multiple LED chips directly onto a substrate to form a single module. Multiple LEDs, minuscule in size, are wired and packaged together into a single ceramic or copper board so that they function as a sole light source.​

When a COB LED package is energized, it appears more like a lighting panel than multiple individual lights as usually the case with other LED packages, like when using several SMD LEDs mounted closely together.​

Chip on Board LED

Images show a very simple Chip-on-Board LED setup, with a single COB mounted on a passive cooler. Left is unlit. Right is lit and dimmed down to make the LEDs visible.

Due to the small size of the LED chips (imagine a quarter), Chip-on-Board technology allows for a much higher packing density than surface mount technology (SMD).

Using COB LEDs as Grow Lights

While there still are reasonable applications to using HID bulbs, the advantages of using COB LED grow lights outweigh the disadvantages.

But the question remails...

Does this technology justify the cost?

The introductory price of using COB LEDs in an indoor garden is initially higher, but they pay themselves off in the long term due to several advantages.

I’m going to take the liberty and compare COB LED’s to the most commonly used high quality lighting of today, namely: HPS, CMH, & MH lights.

To make things easier here’s a nifty little chart for you:

Light Type

µmol/j (ppf/w)

Lifespan

CCT (Kelvin)

Color Rendering Index

COB LED

1.8-2.5

30,000 - 60,000

2700-6500

70-97

Double-ended HPS

1.4-1.8

10,000 - 15,000

2100-3200

20-65

Ceramic Metal Halide

1.1-1.5

15,000 - 20,000

3100-4200

80-96

High Pressure Sodium

0.8-1.7

9,000 - 17,000

2100-3200

20-65

Metal Halide

0.6-1.2

8,000 - 15,000

3200-6000

80-92

T5 Fluorescent

0.6-1.1

8,000 - 10,000

3000-6500

85

Now here’s a breakdown that helps explain the chart:

Improved Electrical Efficiency

For grow lights, efficiency is measured in µmol/j or, more simply, the amount of photosynthetically active photons that are produced per watt consumed at the wall. This can also be interpreted as µmol per watt.

Improved Lifespan

High quality LEDs have hands down the highest usable lifespan of any grow light technology available. Even if the initial investment is higher, a quality LED fixture will last AT LEAST 30,000 hours. So it'll pay itself off over time.

Based on manufacturer literature, double-ended HPS lamps have a life expectancy of 10,000 hours to 90% survival, or 1.65 years when used an average of 16 hours per day or 6,000 hours per year (traditional mogul-base lamps have industry-reported life expectancies of 10,000 to 17,000 hours, to 90% survival, and cost about $40).

The cost of a 1000W, double-ended replacement lamp is about $140, which averages to $28 per year if we assume a lamp will be replaced once in the first five years. Lamp replacement cost increases to $30 to $35 per year when the labor to replace the bulb is included, but this is small compared to the approximately $600 per year annual electric cost to operate the fixture. Adding the cost of lamp replacement increases the five-year cost of operation by about 5%.

By comparison when operated at favorable temperatures, individual LEDs generally have a predicted lifetime (to 70% of the initial light output) of 50,000 hours, about 8.35 years when used an average 16 hours per day or 6000 hours per Year.​

Improved Spectrum​

COB LED CRI

Extracted from the Citizen CLU048 1212 Gen 6 specification sheet provided by Citizen Electronics. (2017)

This is an example of the spectrum you’ll find in most high quality COB LEDs. Please note that although there are always variations between different companies, it’s mostly the same. A 3500K 90CRI COB from any manufacturer should function very closely to any other 3500K 90CRI COB of the same voltage class.

If you’ve read about spectrums before, you’ll notice that no other single-point light source offers such a broad and targeted PAR spectrum.​

Here’s the spectral reading of a few 3100k CMH Bulbs for comparison.​

CMH-spectrum

Improved Light Quality

One of the main reasons that COB LED grow lights have made their way so quickly into many grow rooms is because of their HIGH Color Rendering Index (usually over 80) and broad spectrum.

CRI stands for Color Rendering Index, and describes how the color of a light source changes how an object appears to the human eyes and how well subtle variations in color shades are revealed. The higher the CRI, the more realistic things look.

Regardless of the COB manufacturer, whether CREE, Citizen, Bridgelux, etc. They all offer at least 70 CRI Broad Spectrum chips and which usually can go to up to 97 CRI.

This means no purple, or extreme orange, or red or yellow but high quality white light showing realistic colors.​

Allows replacement of HID bulbs without any loss of light intensity​

Up until now LEDs were a choice for those who needed low power. But not anymore. As of right now LEDs are significantly more efficient at producing photons than any HID technology. Meaning that at the same power consumption, high quality COB LEDs will outperform HID technology at providing quality light for your canopy.​

Better Light Distribution

HIDs and COB’s are both single-point light sources. But since COBs are comparatively easy to handle and position, we have a very different situation.

Instead of using one single light source, COB LEDs can be spaced for better uniformity in order to avoid hotspots or low intensity areas in the grow room.

A practical example would be that instead of having one big 600W HID fixture that would create a hotspot, we could have 6 COB LEDs producing the same amount of light, while consuming less and providing a way better spread.​

Superior Thermal Performance

This is a tricky one, but bear with me. A 500 watt fixture will produce 500 watts of heat, period. Regardless of whether it is an HID, a CFL, or an LED. There’s a common misunderstanding that 500 watts of LEDs is cooler than 500 watts of HID, and while that is usually true, it’s not for the reasons people think.

The reason is mostly Infrared radiation. Far infrared is radiant heat, it’s the same as the feeling of warmth from the sun on your face and the heat from a coal fire. It is even the same form of heat emitted by your own body. And LEDS (unless specifically designed to do so) produce very little infrared light, now compare that spectrum to an HPS and you’ll soon understand why HPS lamps are always so hot.​

COB LEDs Compared to Other Types of Grow Lights

Here's a chart comparing COB LEDs to other types of grow lights. I ranked each light on each quality from 1-5, then added the points up to determine which lights are best.​

Rating

COB LED

DE HPS

HPS

Ceramic MH

MH

T5 Fluorescent

Price

2

4

3

1

3

5

Power Use

5

4

2

3

2

1

Spectrum

5

3

2

4

3

3

Efficiency

5

4

3

3

2

1

Lifespan

5

3

2

3

2

1

Total

22

18

12

14

12

11

Here's a simple breakdown to explain the chart:

COB LEDS vs. HPS

Points for COB LEDs: 22

Where do COB LEDs beat HPS?

  • Power Consumption
  • Spectrum
  • Efficiency
  • Lifespan

Points for HPS: 12

Where do HPS beat COB LEDs?

  • Initial Price

COB LEDS vs. MH

Points for COB LEDs: 22

Where does COB LEDs beat MH?

  • Power Consumption
  • Spectrum
  • Efficiency
  • Lifespan

Points for MH: 12

Where does MH beat COB LEDs?

  • Initial Price

COB LEDS vs. CMH

Points for COB LEDs: 22

Where does COB LEDs beat CMH?

  • Power Consumption
  • Spectrum
  • Efficiency
  • Lifespan

Points for CMH: 14

Where does CMH beat COB LEDs?

  • Easier to Source (more market penetration)

COB LEDS vs. CFL

Points for COB LEDs: 22

Where does COB LEDs beat CFL?

  • Power Consumption
  • Spectrum
  • Efficiency
  • Lifespan

Points for CFL: 11

Where does HPS beat COB LEDs?

  • Initial Price
  • Simple solution for low lighting situations​

COB LEDs vs. Other LEDs​

Remember that COB LEDs are still LEDs, they’re basically the same technology in a different package. So there isn’t much to compare other than light distribution.

While COB LEDS do provide an excellent light intensity, they’re not exactly the best when it comes to spread, because COB LEDs are a single-point light source (meaning all light comes from a single point in space). If we remember that light drops significantly the further away you’re from the source we can see how it’s easy to leave a few “dark” spots when using COB LEDs. This is why manufacturers spend a lot of time designing their lamps figuring out the best spacing for the most even light distribution over the canopy.

And this is where small SMDs have an advantage over a COB LED, being of such a small size you can place many of them very close to each other and form a light panel. The problem here is ensuring that the LEDs have enough light intensity to justify the increased cost of manufacturing such a panel.

Best COB LEDs to Buy

Since as of right now COB LEDs are just entering the market there are very few companies that build COB LED based grow lights. Some of them are ridiculously expensive, but if you know where to look, you’ll find that there are some really, really good opportunities to buy.

I’ve taken the time to gather and review what I believe to be the best options available so you can have an easier time making a choice.​

Best Overall

Pacific Light Concepts, CXP-250​

Pacific Light Concepts, CXP-250

Pros

  • Efficacy: 1.8 µmols/w
  • Lifespan: 50,000hrs
  • Based on: CREE cxb3590
  • Beautiful & clean build quality
  • Waterproof (weatherproof)
  • Scalable design
  • Passive design (no moving parts)
  • ETL Tested and Certified

Cons

  • Pricey at $499.00​

A little more:

The CXP-250 is Pacific Light Concepts latest toy. It’s designed to be used industrially as an array of bars to place over the canopy with a high and even intensity across the entire canopy. An array of CXP-250’s can deliver any intensity the grower desires for any specific crop. And at a starting price of $499.00 their prices aren’t really the most affordable, but their quality is above all the marks!


Timber Grow Lights

Timber Grow Lights, Citizen CLU048 Framework

Pros

  • Best priced COB LED grow light available
  • Efficacy: 2.0 µmols/wLifespan: 50,000hrs
  • Based on: Citizen CLU 048 Gen 6
  • An option for every space configuration
  • Passive design (no moving parts)

Cons

  • Not water / weatherproof

A little more:

With a price range between $229.00 to $1,099.00 Timber definitely has something going on and an option for every need. Their pricing beats a purchasing a Ceramic Metal Halide grow light while adding all the benefits of switching to using COB LEDs, like the improved spectrum, less heat and increased efficiency.

While their design is rather simple they offer a very powerful and useful grow light. For instance, their 200W square fixture is recommended for a 2’ by 2’ space, but it will provide excellent lighting to a 3’ by 3’ space, and even then it will provide a PPFD of 600 µmol/s which is in the high performance range photosynthetic range for ANY CROP. This is affordable power.

Do It Yourself

Anyone can assemble their own COB LED grow lights with just a little guidance!​

When it comes to COB LEDs I always recommend DIY! One of the main advantages of using COB LEDs is that there are only a few of components and that they all fit together in a very straight forward way. You do not need to be an electronics expert to assemble your own grow light anymore! And not only will you be engaging in a very fun project, but you’re also going to save a lot on the cost of labor.​

I’m already working on a DIY COB LED guide so stay tuned if you feel like working on a very neat and simple project!​

DIY COB LED

An example of a fairly basic DIY COB LED Grow Light fixture that I assembled in a few hours to use in my garden.


That’s it! I hope this guide served its purpose and that you now know the benefits and downsides of COB LEDs if you’re thinking about switching your old HIDs over to the newer LEDs technologies.

Remember that technology is always evolving and what is true today may not be true tomorrow. So keep an eye out for new guides in case any new breakthroughs happen. And if they do, I’ll make sure to write another guide to dispel all of your doubts!

If you have any doubts or questions or think there’s something I didn’t cover, feel free to leave a comment and i’ll do my best to help!

157 Shares
This post was last updated on

31 thoughts on “The COB LED Grow Light Explained and Reviewed

  1. Great article and one of the only on the entire internet that suggests GOOD led lights! This information is still very much relevant now in the summer of 2018. Great job!

  2. Hi Kevin,

    Nice article.
    Facts about Leds:
    Up to 40% of electricity is converted to visible light. All the rest is heat.
    The other types convert to heat, visible and IR light, the last converting to heat when the photons hit something, like human skin.

    Efficiency drops as power increase.
    10 of any LED run at 10% of FULL power will produce more light, and less heat than 1 LED at full power.
    Double is not unknown.
    Efficacy is usually rated at lower power, often 1/3 of full.

    CREE has a Product Characteristics Tool which shows various factors and how they interact.
    Great for DIY.

  3. Thanks for the very informative article. I recently bought a BESTVA 600W COB 2 light and my plants seem really happy. But my light emits the regular bright LED colours. Does this mean that they are not truly COB lights and are just regular LED?

    Any information is appreciated

    • There are a few CLU 048 Citizen models, so you’d have to be more specific. But regardless of the model Citizen chips are usually a lot more affordable than the Cree 3590, is it worth the price difference?

      If you’re trying to get the best bang for your buck go with the Citizen, as far as i know the only advantage that this specific cree chip has over the 048’s is very good efficiency when driven at very low currents.

    • I performed a lifetime cost analysis between the Citizen and CREE offerings. At identical light outputs, the difference in cost was under $10 USD at 15¢ and 25¢ / KWh over 50,000 hrs.

      I went with the Citizen CLU048s. My reasoning was that they were cheaper to upgrade as technology changes.

  4. I have bought 300Watt and 400Watt, 12V COB light panels for as little as $10 US, go to alibaba.com, they have many COB light distributors, with a variety of wattage

  5. Hi Kevin,

    Thanks for mentioning Timber in your article – we certainly appreciate it. If you or any of your readers have questions about our lights, or COBs in general, I’d be happy to assist.

    Also, our new fixtures feature an upgraded frame design with movable heat sinks.

    Hope you have a good day.

    Regards,
    Dan

  6. If you are looking for cobs check out kingbrite. They have the cheapest diy cob kits all top quality cree cxb 3590 , vero 29 gen 7, etc. Complete everything they have they based in China but fast delivery here in Canada to me. Just google them get your lights from them safe a bundle and get a top quality cob or cobs how ever many u need.

  7. Got a led grow light from Unitfarm recently,also with CREE led diodes!Very bright, I really like the openess and the reflector for the led. COB is very popular recently,What is the biggest difference between CREE cxb3590 and other ordinary CREE ? Interested in DIY!But sometimes I am worry it is not safe??

    • CREE manufactures many kinds of Light Emitting Diodes, and many of them differ in size, color and application. A COB is actually a LED manufacturing method, think of tiny diodes bunched together into a “bigger” diode. Cree COBS are just made using CREE LEDS, that’s all.

      There shouldn’t be much difference if your grow light is using the latest CREE LEDs.

      Regarding DIY and Safety. When working with Electrical components you should always place safety first. If you can follow simple instructions and use caution you should be completely safe.

      Hope that answers your questions!

    • I highly recommend that ANY electrical feed to a grow op includes a GFI, either as a receptacle or circuit breaker, outside of the grow op.

  8. Hi! I’m super interested in that DIY guide you mentioned writing at the end of the article. Any chance that you could share that, or perhaps there’s already a guide out there that I (and we) could enjoy?
    Thanks!

    • I’m in Canada and recently bought from Kingbrite LED. The cost was:
      Parts Received and Installed:
      CLU048-1216C4 3000K 80CRI 8 $ 13.00 $104.00
      thermal tape 8 $ 0.30 $ 2.40
      Ideal 50-2204CT + Ideal 50-2100AN + Reflector 8 $ 4.60 $ 36.80
      Pre-drilled heatsink (163mm) 8 $ 15.00 $120.00
      Wago 222-412 5 $ 0.40 $ 2.00
      MW HLG-240H-C1750B 2 $ 55.00 $110.00
      Shipping cost 1 $115.00 $115.00
      Charge by PayPal(3.8%) 1 $ 18.62 $ 18.62
      Subtotal Shenzhen KingBrite Electronics Co Ltd $508.82 USD / $682.22 CAD

      as of 23/03/2018

  9. I’m right with you, I’ve used my share of different grow lights in my days and about 8 months ago I built some COB LED’s.
    My vegetative light I’m running 6 Bridgelux Vero 13s with 150w of meanwell HLG-C driver passively cooled with pin-fin heatsinks.
    My main flowering light I’m running 16 Bridgelux Vero 18’s driven by 2 Meanwell HLG-C240 for a total of 500 watts.
    I’ve never seen such healthy happy plants indoors. My 500w diy COB is outperforming what a 1000w HPS did in the same space. Temps and humidity are no longer things that take massive efforts and energy to control, everything is in check with a small intake fan, my exhaust fan I now only have to run at about 35-40%. Room that my grow tents are sat in no longer need additional AC unit to keep cool, the house AC system blowing into the room keeps temps and humidity in perfect levels.
    I highly recommend anyone looking to get into LED technology to skip the “burple” LED’s and go right into COB technology, watch some videos, do some reading and learn to build your own, I probably saved close to $1000 on the two lights I built myself.
